DIAL SIZE

:

100 mm, 150 mm

ACCURACY

:

+/-, 1.5% of range span

SENSING ELEMENT

:

Steel diaphragm.

DIAPHRAGM PROTECTION

:

Standard Teflon PTFE. Optional: tantalum For corrosive / silver for chlorine (on request).

CASE & BEZEL

:

Cast aluminum weatherproof stove enameled Black with screwed inner bezel of abs plastic / SS 304.

MOVEMENT MATERIAL

:

Brass or AISI 304 SS

CONNECTION

:

1/2 "BSP screwed (standard), other connection / Flanges on request.

MOUNTING

:

Direct with bottom / back entry.

POINTER

:

Micrometer zero adjustment type.

TOP CHAMBER

:

Cast aluminum / SS 304 depending upon the case materials.

BOTTOM CHAMBER

:

Standard AISI 316 SS. Optional : Teflon coated.

RANGE

:

0 , 1, 1.6, 2.5, 4, 6,7, 10, 16 & 25.Kg/cm2.    Vacuum & Compound: -760 mmhg  TO  0, 0.6, 1, 1.5, 3, 5, 9, 15, & 24 Kg/cm2. Accessories available: safety glass electric Contact (only in 100 mm & 150 mm).
